- Switch Capacity
- 24Gbps Full duplex
- Uplink Ports
- 2 x 1000Mbps RJ45 ports + 2 x 1000Mbps SFP ports
- Poe Power Budget
- 96W
- Surge Protection
- Common mode/RJ45 port: 4KV Differential mode/RJ45 port: 2KV Common mode/Power board: 2KV Differential mode/Power board: 2KV
- ESD
- Air discharge: 8KV; Contact discharge: 6KV
- Ethernet Port Light
- Green light off: Link is disconnected Green light on: Link is connected Green light flash: Data Transmitting
- Network Port
- 12
- Transmission Distance
- 0-100m/1000Mbps or Port 7-8 Max. 250m/10Mbps via Cat.5e or more under Extend mode
- Poe Ports
- 8, 1000Mbps; RJ45 ports; Max. 30W Output of Single Poe Port
- Poe Power Supply
- 1/2(+), 3/6(-)
- Poe Standard
- IEEE802.3af, IEEE802.3at
- Packet Forwarding Rate
- 1.488Mpps/port
- MAC Address List
- 2K
- Power Source
- Input: 100-240V AC, 50/60Hz, Built-in Power Supply
- Operating Temperature
- -10°C ~ 50°C
- Humidity
- 10%-95%, non-condensing
- Storage Temperature
- -40°C ~ 70°C
- Dimension
- 220 x 161 x 44 mm
