- Tag
- 32
- Area
- 16
- Zones
- 64 (up to 48 PIRCAMs)
- Installer
- 1
- User
- 30
- Admin
- 1
- Voice Prompt
- Supported
- Loudspeaker Built-in
- Supported
- Memory Log Stored
- 5000
- Programming Tools
- Hik-Connect, Hik-Pro Connect, Web Portal, IVMS4200, Convergence Cloud
- Firmware Upgrade
- APP/Web Portal
- Arm Modes
- Away/Stay
- Automatic Arm/Disarm Timers
- Supported
- Forced Arming with Open Zones
- Supported
- Diagnostics via the APP or Web
- Supported
- ARC Protocol
- SIA DC09(SIA level 2, Contact ID), ISUP, ISAPI (SDK)
- Hik-IP Receiver & Hik-IP Receiver Pro (Sur-Gard & Ademco 685)
- Supported
- Supports Video Verification and Remote Control
- Supported
- User APP for Operating
- Supported
- Installer APP for Programming
- Supported
- Web Server for Maintenance (Offline Configuration)
- Supported
- RS232 Output
- Supported
- SIM Slot
- Single
- RF Transmission
- 433 MHz
- Wireless Security
- Frequency Hopping 128 AES Encryption
- GPRS on Board
- Supported
- Power Supply
- Built-in Power Supply
- Battery Type
- Built-in Onboard Battery Li
- Battery Life Span
- Up to 12 hours at normal temperature (Battery life decreases at low temperatures)
- Wireless Transmission
- Wired Network Supported
- Wi-Fi Standard
- Supported
- Display
- LEDs Status (Arm/Disarm, Alarm, Tamper, Fault, Cloud, Power)
- Operation Temperature
- -10°C to +55°C
- Shell Material
- Plastic
- Dimensions (WxHxD)
- 170.0 mm x 170.0 mm x 38.6 mm
- Weight
- 557.5 g (19.7 oz)
- Color
- White
- Device Management
- Keyfob: 32, Wireless Sounder: 4 (2 internal + 2 external), Keypad: 8 (Including Tag Reader), Wireless Repeater: 2, Multi Transmitter: 4, PIR Cam: Supported
