- Uplink Ports
- 2, 1000Mbps; Transmission Distance: 0-100m
- Network Protocol
- IEEE802.3i/802.3u/802.3x/802.3af/802.3ab
- Switch Capacity
- 20Gbps Full duplex
- Packet Forwarding Rate
- 1.488Mpps/port
- PWR (Power Indicator)
- Light on: Powering, Light off: No Power
- Poe Ports
- 8, 1000Mbps; RJ45 ports; Max. 30W Output of Single Poe Port
- Network Port
- 10
- MAC Address Table
- 2K
- Poe Standard
- IEEE802.3af, IEEE802.3at
- Poe Power Supply
- 1/2(+), 3/6(-)
- Transmission Distance
- 0-100m/1000Mbps or Port 7-8 Max. 250m/10Mbps via Cat.5e or more under Extend mode
- Poe Power Budget
- 96W
- Poe Feature
- All ports support MDI/MDIX
- ESD
- Air discharge: 8KV; Contact discharge: 6KV
- Surge Protection
- Common mode/RJ45 port: 4KV Differential mode/RJ45 port: 2KV Common mode/Power board: 2KV Differential mode/Power board: 2KV
- VLANs
- Support
- RJ-45 ACT Indicator
- Green light off: Link is disconnected Green light on: Link is connected Green light flash: Data Transmitting
- Watchdog
- Support
- Forwarding Mode
- Store-and-forward
- Power Source
- Built-in Power Supply, Input: 100-240V AC, 50/60Hz
- Operating Temperature
- -10°C ~ 50°C
- Storage Temperature
- -40°C ~ 70°C
- Working Humidity
- 10%-95%, non-condensing
- Dimensions
- 200mm x 118mm x 44mm
- Color
- Black
- Weight
- 0.8Kg (not include input cable & packaging)
