- Brand & Model
- Gigabyte Z890 D PLUS DDR5
- Chipset & Socket
- Intel Z890 Express Chipset, LGA1851 Socket
- Processor Support
- Intel Core Ultra Processors
- Memory Support
- 4 x DDR5 DIMM Slots, Dual Channel, Up to 256GB, 9466+ MT/s (OC), Intel XMP & CUDIMM Support
- Display Output
- 1 x DisplayPort 2.1, Up to 4096 x 2304 @ 60Hz, HDCP 2.3 Support (CPU Dependent)
- Expansion Slots
- 1 x PCIe 5.0 x16 Slot, 2 x PCIe 4.0 x16 Slots (Running at x4)
- Storage Connectivity
- 4 x M.2 Slots (1 x PCIe 5.0, 3 x PCIe 4.0; One Also Supports SATA), 4 x SATA 6Gb/s Ports, RAID 0/1/5/10 Support
- Audio
- Realtek High Definition Audio CODEC, 2/4/5.1-Channel Audio
- LAN Connectivity
- Realtek 2.5GbE LAN (2.5Gbps/1Gbps/100Mbps)
- USB Connectivity
- USB 3.2 Gen 2 Type-C & Type-A, USB 3.2 Gen 1 Type-C & Type-A, USB 2.0/1.1 Ports (Rear & Internal Headers)
- Additional Features
- Q-Flash Plus, GIGABYTE Control Center, Smart Backup, RGB & ARGB Headers, TPM Header, Thunderbolt 5 Add-In Card Connectors, Fan & Temperature Monitoring
- Form Factor & OS Support
- ATX (30.5 x 24.4cm), Windows 11 64-bit & Windows 10 64-bit Support
