- Switch Capacity
- 12 Gbps Full duplex
- Uplink Ports
- 2, 1000Mbps; Transmission Distance: 0-100m
- Poe Power Budget
- 48W
- Anti-thunder Level
- Common mode: 2KV; Differential mode: 2KV
- ESD
- Air discharge: 1.5KV; Contact discharge: 1.5KV
- Ethernet Port Light
- Light off: Link is disconnected Red light on: Powering but data disconnected Light flash quickly: Data Transmitting
- Network Port
- 6
- Transmission Distance
- 0-100m/100 Mbps
- Poe Ports
- 4, 1000Mbps; RJ45 ports; Max. 30W Output of Single PoE Port; Transmission distance: 0-100m
- Poe Power Supply
- 1/2(+), 3/6(-)
- Poe Standard
- IEEE802.3af, IEEE802.3at
- Packet Forwarding Rate
- 1.488Mpps/port
- MAC Address List
- 2K
- Power Source
- Built-in Power Supply, Input: 110-264V AC, 50/60Hz
- Operating Temperature
- -10°C~ -50°C
- Humidity
- 10%-95%, non-condensing
- Storage Temperature
- -40°C~70°C
- Dimension
- 202mm x 140mm x 45mm (L x W x H)
