- Feature
- Description
- Processor
- Qualcomm 560MHz CPU, MIPS 74Kc
- Memory
- 64MB DDR2 RAM, 8MB Flash
- Interface
- 1 × 10/100Mbps Shielded Ethernet Port (LAN/PoE) 1 × Reset Button
- Power Supply
- Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) Voltage range: 16-27VDC
- Power Consumption
- 7.41 W
- Dimensions (W x D x H)
- 366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.)
- Antenna Gain
- 23dBi
- Antenna Beamwidth
- 9° (Azimuth), 7° (Elevation)
- Protection
- 15KV ESD Protection 6KV Lightning Protection
- Enclosure
- Material: Outdoor PC stabilized plastic Weatherproof: IP65 water and dust proof design
- Feature
- Description
- Wireless Standards
- IEEE 802.11a/n
- Proprietary Protocol
- TDMA Mode (with Pharos MAXtream enabled)
- Wireless Speeds
- Up to 300Mbps (40MHz, Dynamic) Up to 144.4Mbps (20MHz, Dynamic) Up to 72.2Mbps (10MHz, Dynamic) Up to 36.1Mbps (5MHz, Dynamic)
- Frequency
- 5.15~5.85GHz (Available operating frequency may vary depending on the region)
- Transmit Power
- Max. 25dBm (Adjustable power by 1dBm)
- Feature
- Description
- Network Configuration
- WAN: Static/Dynamic/PPPoE/L2TP/PPTP LAN: Static/Dynamic/DHCP Forwarding: ALG/UPnP/Virtual Server/Port Trigger Security: SPI Firewall/ Ping Forbidden/DoS Protection Access Control Static Routing Bandwidth Control IP & MAC Binding
- Wireless Configurations
- Pharos MAXtream TDMA Technology Selectable Channel Width: 5/10/20/40MHz Auto Channel Selection Transmit Power Control Dynamic Frequency Selection (DFS) WDS Enable/Disable Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) 64/128/152-bit WEP Encryption SSID Broadcast Enable/Disable Multi-SSID with VLAN Tagging (AP Mode only) Distance/ACK Timeout Setting Wireless MAC Address Filter Wireless Advanced: Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
- Feature
- Description
- Management Options
- Discovery and Remote Management via Pharos Control Application HTTP/HTTPS Web-based Management System Log SNMP Agent (v2c) Ping Watch Dog Dynamic DDNS SSH Server
- System Tools
- Indicators: Signal Strength/Noise/Transmit CCQ/CPU/Memory Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP Spectrum Analyzer Speed Test Ping Traceroute
- System-level Optimizations
- Optimized IGMP Snooping/Proxy for multicast applications Hardware Watchdog
- Feature
- Description
- Dimensions (W x D x H)
- 85.8 × 43.9 × 29.7 mm
- Interfaces
- 1 AC Jack with Earth Ground 1 × 10/100Mbps Shielded Ethernet Port (Power + Data) 1 × 10/100Mbps Shielded Ethernet Port (Data)
- Button
- Remote Reset Button
- Power Status LEDs
- Green
- Input
- 100-240VAC, 50/60Hz
- Output
- 24VDC, 0.5A Max +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
- Efficiency
- > 84.29%
- Certifications
- CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
- Feature
- Description
- Certification
- CE, FCC, IC, RoHS, IP65
- Package Contents
- Outdoor Wireless CPE 24V 0.5A Passive PoE Adapter Pole Mounting Straps AC Power Cord Installation Guide
- System Requirements
- Microsoft Windows 98SE, NT, 2000, XP, Vista™, Windows 10, 8, 7, MAC OS, NetWare, UNIX or Linux. Recommended Browsers: Google Chrome, Safari, Firefox. (IE browsers not recommended)
