- CPU Support
- LGA1700 socket: Supports 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold, and Celeron® Processors. L3 cache varies with CPU.
- Chipset
- Intel® B760 Express Chipset
- Memory
- - 2 x DDR5 DIMM sockets supporting up to 96 GB (48 GB single DIMM capacity) - Supports DDR5 8000(O.C.) to 4000 MT/s - Dual channel architecture - Supports ECC Un-buffered DIMM 1Rx8/2Rx8 (non-ECC mode) - Supports non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 - Supports XMP memory modules
- Onboard Graphics
- Integrated Intel® HD Graphics: - 1 x D-Sub (max 1920x1200@60Hz) - 1 x HDMI (max 4096x2160@60Hz) * HDMI 2.1, HDCP 2.3 support ** Native HDMI 2.1 TMDS ports (Graphics spec may vary depending on CPU)
- Audio
- - Realtek® Audio CODEC - High Definition Audio, 2/4/5.1/7.1-channel * Audio jack functions customizable via software - S/PDIF Out supported
- LAN
- Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
- Expansion Slots
- CPU: - 1 x PCIe x16 (PCIe 4.0, runs at x16) * Supports only GPU or NVMe SSD Chipset: - 1 x PCIe x1 (PCIe 3.0, runs at x1)
- Storage Interface
- CPU: - 1 x M.2 (2280, PCIe 4.0 x4/x2) - M2A_CPU Chipset: - 1 x M.2 (2280, PCIe 4.0 x4/x2) - M2P_SB - 4 x SATA 6Gb/s - RAID 0, 1, 5, 10 supported for SATA
