- Processor
- Embedded MCU Processor
- Operation System
- Embedded Linux Operation System
- Display Resolution
- 1024 × 600
- Display Screen
- 7-inch colorful TFT screen
- Audio Compression Rate
- 64 Kbps
- Audio Compression Standard
- G.711 U
- Audio Input
- Built-in omnidirectional microphone
- Audio Output
- Built-in loudspeaker
- Audio Quality
- Noise suppression and echo cancellation
- Ethernet
- 10/100 Mbps Self-Adaptive Ethernet
- Network Protocol
- TCP/IP, RTSP
- I/O Input
- 4
- I/O Output
- 2
- Power Supply
- 12 VDC/PoE (IEEE 802.3af)
- Power Consumption
- ≤10 W
- Working Temperature
- -40° C to +60° C (-40° F to 140° F)
- Working Humidity
- 10% to 95%
- Dimension (L × W × D)
- 200 mm × 140 mm × 15.1 mm (7.9" × 5.5" × 0.6")
- Weight (with packaging)
- 683 g
- Weight (without packaging)
- 355 g
- IP Protection Level
- IP65
- Memory
- 128 MB
- Dimensions (L × W × H)
- 98 mm × 99.8 mm × 43.9 mm (3.86" × 3.93" × 1.73")
