- Feature
- Specification
- Input Voltage
- 180~264VAC
- Output Voltage
- 12V DC
- Current Range
- 0~20A
- Rated Power
- 240W
- Ripple & Noise (max.)
- 100mVp-p
- Voltage Adjustment Range
- 11.4~13.2V
- Line Regulation
- 1.0%
- Voltage Tolerance
- 2.0%
- Setup Rise Time
- 600ms, 30ms at full load
- Hold Up Time (Typ.)
- 13ms at full load
- Load Regulation
- 5.0%
- Temperature Coefficient
- 0.03%/°C (0~50°C)
- Frequency Range
- 47~63HZ
- Efficiency (Typ.)
- 84%
- AC Current (Typ.)
- 5A/115VAC, 3A/230VAC
- Inrush Current (Typ.)
- 20A/115VAC, 40A/230VAC
- Over Load
- 110~200% rated output power, Protection type: Shut down O/P, re-power
- Isolation Resistance
- I/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC / 25°C/ 70% RH
- Working Humidity
- 20~90% RH Non-condensing
- Vibration
- 10 ~ 500Hz, 3G 10min./1 cycle, 60min.each along X, Y, Z axes
- Dimension
- 196(L) x 114(W) x 55mm(H)
- Storage Temperature
- -20~+85°C, 10~95%RH
- Working Temperature
- -20~+40°C
- Withstand Voltage
- I/P-O/P: 1.5KVAC, I/P-FG: 1.5KVAC, O/P-FG: 0.5KVAC
