- Tag
- 48
- Area
- 32
- Zones
- 96 (up to 48 PIRCAMs)
- Onboard video clips
- 4
- Installer
- 1
- User
- 46
- Admin
- 1
- Voice Prompt
- Supported
- Loudspeaker built in
- Supported
- Tag reader built in
- Supported
- Memory Log stored
- 5000
- Programming tools
- Hik-Connect/Hik-ProConnect/Web Portal/IVMS4200/Convergence Cloud
- Firmware upgrade
- APP/Web Portal
- Arm modes
- Away/Stay
- Automatic Arm/Disarm Timers
- Supported
- Forced Arming with Open Zones
- Supported
- Diagnostics via the APP or Web
- Supported
- ARC protocol
- SIA DC09(SIA level 2, Contact ID), ISUP, ISAPI (SDK)
- Hik-IP Receiver & Hik-IP Receiver Pro (Sur-Gard & Ademco 685)
- Supported
- Video verification and remote control
- Supported
- User APP for operating
- Supported
- Installer APP for programming
- Supported
- Web server for maintenance (offline configuration)
- Supported
- RS232 output
- Supported
- SIM slot
- Dual
- RF transmission
- Two-way Wireless Communication Support
- RF Frequency
- 433Mhz
- Wireless Security
- Frequency Hopping 128 AES Encryption
- 3/4G on board
- Supported
- Power supply
- Built-in power supply
- Battery type
- Built-in on board Battery Li
- Battery life span
- Up to 12 hours at normal temperature
- Wired network
- Supported
- Wi-Fi Standard
- Supported
- LEDs Status
- Arm/Disarm, Alarm, Tamper, Fault, Cloud, Power
- Operation temperature
- -10 °C to +55 °C
- Shell material
- Plastic
- Dimension (WxHxD)
- 170.0 mm (6.7") x 170.0 mm (6.7") x 38.6 mm (1.5")
- Weight
- 557.5 g (19.7 oz)
- Color
- White
- Keyfob
- 48
- Wireless sounder
- 6 (3 internal + 3 external)
- Keypad
- 8 (Including Tag reader)
- Wireless Repeater
- 4
- Multi Transmitter
- 6
- PIR Cam
- Supported
