Name: QNAP TS-664 6 Bay NAS Box
Brand: QNAP
SKU: TS-664-8G
Availability: OutOfStock

QNAP TS-664 6 Bay NAS Box

Product ID: A0098
Item CD: THIAQ
Model: TS-664
Warranty: 3 Years From QNAP Service Center
Product URL: View Product

Based on 0 reviews. - Write a review

Out Of Stock

Ex Tax: ₹0

Qty

Add to Cart

Add to Wish List Compare this Product

Description
Reviews

Attribute	Specification
Model	TS-664-8G
CPU	Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz
CPU Architecture	64-bit x86
Graphic Processors	Intel® UHD Graphics
Floating Point Unit	Yes
Encryption Engine	AES-NI
Hardware-accelerated Transcoding	Yes
System Memory	8 GB SODIMM DDR4 (1 x 8 GB)
Maximum Memory	16 GB (2 x 8GB)
Memory Slot	2 x SODIMM DDR4
Flash Memory	4GB (Dual boot OS protection)
Drive Bay	6 x 3.5-inch SATA 6Gb/s
Drive Compatibility	3.5-inch SATA HDDs, 2.5-inch SATA SSDs
Hot-swappable	Yes
M.2 Slot	2 x M.2 2280 PCIe Gen 3 x1 (Compatible with NVMe SSDs, Gen 3 and above)
SSD Cache Acceleration Support	Yes
2.5 Gigabit Ethernet Port	2 (2.5G/1G/100M)
5 Gigabit Ethernet Port	Optional via PCIe expansion card
10 Gigabit Ethernet Port	Optional via PCIe expansion card
Wake on LAN (WOL)	Yes
Jumbo Frame	Yes
PCIe Slot	1 (PCIe Gen 3 x2)
USB 2.0 Port	2
USB 3.2 Gen 2 Port	2 x Type-A
IR Sensor	Optional (QNAP RM-IR004 remote control)
HDMI™ Output	1, HDMI™ 2.1 (up to 4096 x 2160 @ 60Hz)
Form Factor	Tower
LED Indicators	Power/Status, LAN, USB, HDD1-6
Buttons	Power, USB Copy, Reset
Dimensions (HxWxD)	165 × 235 × 226.5 mm (excluding foot pad)
Weight (Net)	2.94 kg
Weight (Gross)	5.1 kg
Operating Temperature	0 - 40 °C (32°F - 104°F)
Storage Temperature	-20 - 70 °C (-4°F - 158°F)
Relative Humidity	5-95% RH non-condensing (wet bulb: 27˚C/80.6˚F)
Power Supply Unit	120W adapter, 100-240V
Power Consumption: HDD Sleep Mode	23.22 W
Power Consumption: Operating Mode, Typical	44.02 W (tested with drives fully populated)
Fan	2 x 90mm, 12VDC
System Warning	Buzzer
Kensington Security Slot	Yes
Standard Warranty	3 Years
Max. Number of Concurrent Connections (CIFS) - with Max. Memory	1,500

Tags: Power , HDD , USB , Processor , System Memory , CPU , Server , Ram , Storage , Hard Disk , Backup , Lan , 6-BAY NAS , DESKTOP , INTEL CELERON , SATA DRIVE BAY , HDMI
