- Feature
- Specification
- AC Input Voltage
- 150~265VAC
- DC Output Voltage
- 12VDC
- Rated Power
- 48W
- Ripple & Noise (max.)
- 140mV (max)
- Voltage Adj. Range
- NA
- Device
- Primary-Side Regulation
- Device Frequency
- 132KHz
- VDS Voltage
- 616V (max)
- Line Regulations
- 1%
- Load Regulations
- 5%
- SCP
- Output short-circuit protection
- OPP, OCP
- Output overload/over-current protection
- OVP
- Output overvoltage protection, auto-restart or latching
- Line UV
- Line brown-in/out protection
- OV
- Line overvoltage shutdown extends line surge withstand
- OTP
- Accurate thermal shutdown, hysteretic or latching
- Efficiency (Typ.)
- 83%
- Frequency Range
- 47~63Hz
- Storage Temperature
- 0-50°C
