- Feature
- Specification
- Network Port
- PoE (1~6): 10/100Mbps PoE ports (RJ45) PoE (7~8): 10/100Mbps PoE ports (RJ45), Support bt 60W High Power LAN: 10/100Mbps uplink ports (RJ45)
- Network Standard
- IEEE 802.3i 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3x Flow Control, IEEE 802.3af/at/bt Power over Ethernet
- Transmission Rate
- 200Mbps Full Duplex; 10 or 100Mbps Half Duplex
- Transmission Distance
- 1~2 ports: 250m @ 10Mbps 3~8 ports: 130m @ 100Mbps
- MAC Address List
- 2K
- Bandwidth
- 2.0 Gbps
- Network Latency
- (10 to 100Mbps): ≤16μs (using 64-byte package size)
- Frame Filter & Transmission Rate
- 14,800 pps max for 10Mbps port, 148,800 pps max for 100Mbps port
- Power Budget
- 120W
- Power Input
- AC 180~240V, Total ≤120W
- Power Output
- PoE 1~6 Port: 1/2(+52V), 3/6 (GND) ≤30W PoE 7~8 Port: 1245(+53V), 3678 (GND) compatible 1/2 (+52V), 3/6 (GND) ≤60W
- Watchdog
- Port 1~8
- Lightning Protection
- 6KV, Per: IEC61000-4-5
- ESD Protection
- 8KV, Per: IEC61000-4-2
