- Category
- Specification
- Operation System
- Linux
- ROM
- 32 MB
- RAM
- 256 MB
- Processor
- Embedded high-performance processor
- Screen Size
- /
- Operation Method
- /
- Type
- /
- Resolution
- /
- Lens
- 1
- Resolution
- Main stream: 1920 × 1080p and 1280 × 720p Sub stream: 640 × 480p
- FOV
- Horizontal: 124° Vertical: 75°
- Wide Dynamic Range (WDR)
- Digital WDR/76.9 dB
- Supplement Light
- IR light, up to 3 m
- Video Compression Standard
- H.264
- Audio Input
- 1 built-in omnidirectional microphone
- Audio Compression Standard
- G.711 U, G.711 A, Opus, AAC-LD, AAC-LC, G.726, G.722.1
- Audio Output
- 1 built-in loudspeaker
- Audio Compression Bitrate
- 64 Kbps
- Audio Quality
- Noise suppression and echo cancellation
- Volume Adjustment
- Adjustable
- User Capacity
- 2000
- Card Capacity
- 10000
- Linked Indoor Station Capacity
- 4 (main indoor station)
- Sub Door Station Capacity
- 16
- Network Protocol
- TCP/IP, RTSP
- Wi-Fi
- IEEE802.11b, IEEE802.11g, IEEE802.11n
- Bluetooth
- /
- 3G/4G
- /
- Received Frequency
- 2.4 to 2.4835 GHz
- Transmitted Frequency
- 2.4 to 2.4835 GHz
- Bandwidth
- 20/40 MHz
- Frequency Power
- 802.11b: 15 dBm ± 1.5 dBm 802.11g: 15 dBm ± 1.5 dBm 802.11n(ht20): 14 dBm ± 1.5 dBm 802.11n(ht40): 12 dBm ± 1.5 dBm
- Card Reading Frequency
- 13.56 MHz
- Alarm Input
- 4
- Network Interface
- 1 RJ-45, 10/100 Mbps self-adaptive
- TAMPER
- 1
- Exit Button
- 2
- RS-485
- 1
- USB
- /
- Wiegand
- /
- TF Card
- Reserved
- Alarm Output
- /
- Lock Control
- 2 relays, Max. 30 VDC 2 A
- Door Contact Input
- 2
- Button
- 4 physical buttons
- Installation
- Surface mounting
- Indicator
- 3
- Weight
- Net: 0.400 kg Gross: 0.658 kg
- Protective Level
- IP65, IK08
- Working Temperature
- -40 °C to 53 °C (-40 °F to 127.4 °F)
- Working Humidity
- 10% to 95% (no-condensing)
- Dimension (W × H × D)
- 174 mm × 91 mm × 29 mm (6.9" × 3.6" × 1.1")
- Battery
- /
- Application Environment
- Outdoor
- Language
- English, French, Portuguese, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Slovak
