- Operating System
- Linux
- ROM
- 32 MB
- RAM
- 128 MB
- Processor
- Embedded high-performance processor
- Screen Size
- 7-inch
- Operation Method
- Capacitive touch screen
- Type
- Colorful TFT
- Resolution
- 1024 × 600
- Lens
- /
- Resolution
- /
- FOV
- /
- Wide Dynamic Range (WDR)
- /
- Video Compression Standard
- /
- Focal Length
- /
- Audio Input
- 1 built-in omnidirectional microphone
- Audio Compression Standard
- G.711 U, G.711 A, G.722.1
- Audio Output
- 1 built-in loudspeaker
- Audio Compression Bitrate
- 64 Kbps
- Audio Quality
- Noise suppression and echo cancellation
- Volume Adjustment
- Adjustable
- Message Capacity
- TF card inserted: 200 captured pictures, 200 alarm records; Without TF card: 2 MB RAM for picture storage, 200 alarm records
- Notice Capacity
- 200
- Linked Indoor Extensions Capacity
- 16
- Linked Doorphone Capacity
- 17
- Linked Network Camera Capacity
- 16
- Network Protocol
- TCP/IP, SIP, RTSP
- Wi-Fi
- 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
- Bluetooth
- /
- 3G/4G
- /
- Zigbee
- /
- Alarm Input
- 8
- Network Interface
- 1 RJ-45 10/100 Mbps self-adaptive
- TAMPER
- /
- RS-485
- 1 RS-485 (Half duplex)
- USB
- /
- TF Card
- Support TF card, up to 128 G
- Alarm Output
- 2
- Lock Control
- 2 relays, Max. 30 VDC 0.3 A
- Button
- /
- Installation
- Surface mounting
- Indicator
- /
- Weight
- Net weight: 355 g (0.8 lb), Gross weight: 683 g (1.5 lb)
- Protective Level
- /
- Working Temperature
- -10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity
- 10% to 90% (no-condensing)
- Dimension (W × H × D)
- 200 mm × 140 mm × 15.1 mm (7.9" × 5.5" × 0.6")
- Battery
- /
- Application Environment
- Indoor
- Power Consumption
- ≤ 5 W
- Language
- English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese (Brazil), Spanish, Hebrew, Romanian, Turkish, Estonian, Danish, Swedish, Norwegian, Finnish, Vietnamese, Croatian, Slovenian, Serbian, Arabic, Portuguese (Portugal), Lithuanian, Uzbek, Kazakh, Mongolian, Ukrainian
