- Operation System
- Embedded Linux operation system
- Flash
- 32 MB
- RAM
- 128 MB
- Camera
- 2MP HD camera
- Night Vision
- Low illumination IR supplement mode: 3 m
- Backlight Compensation
- Support
- Digital Noise Reduction
- Support
- WDR
- True WDR
- Field of View
- Horizontal: 129°, Vertical: 75°
- Video Compression Standard
- H.264
- Stream
- Main stream: 1080p@30fps, 720p@25fps; Sub stream: D1@25fps
- Motion Detection
- Support
- Flash-avoid Frequency
- 50 Hz, 60 Hz
- Audio Input
- Built-in omnidirectional microphone
- Audio Output
- Built-in loudspeaker
- Audio Quality
- Noise suppression and echo cancellation
- Audio Compression Standard
- G.711 U
- Audio Compression Rate
- 64 Kbps
- Audio Intercom
- Two-way audio communication
- Network Protocol
- TCP/IP, RTSP
- Wired Network
- 10/100 Mbps Ethernet
- RS-485
- 1
- Alarm Input
- 4
- Debugging Port
- 1
- Grounding
- 1
- TAMPER Switch
- 1
- Power Consumption
- ＜ 10 W
- Working Temperature
- -40° C to 53° C (-40° F to 127.4° F)
- Working Humidity
- 10% to 95%
- Dimension
- 138 mm × 65 mm × 27 mm
- Installation
- Surface mounting
- Protection Level
- IP65
- Indicator
- 2
- Power Supply
- IEEE802.3af, standard PoE; 12 VDC
- Operation System
- Embedded Linux operation system
- Memory
- 128 MB
- Flash
- 32 MB
- Display Screen
- 7-inch colorful TFT screen
- Display Resolution
- 1024 × 600
- Operation Method
- Capacitive touch screen
- Audio Input
- Built-in omnidirectional microphone
- Audio Output
- Built-in loudspeaker
- Audio Quality
- Noise suppression and echo cancellation
- Audio Compression Standard
- G.711 U
- Audio Compression Rate
- 64 Kbps
- Wired Network
- 10/100 Mbps self-adaptive
- Wireless Network
- Wi-Fi 802.11 b/g/n
- Protocol
- TCP/IP, SIP, RTSP
- RS-485
- 1
- Alarm Input
- 8-ch alarm inputs
- Relay Output
- 2
- TF Card
- Max 32 G, SD 2.0 or lower version
- Power Consumption
- ≤ 6 W
- Working Temperature
- -10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity
- 10% to 90%
- Dimension (L × W × H)
- 200 mm × 140 mm × 15.1 mm (7.9" × 5.5" × 0.6")
