- Feature
- Specification
- VAC Voltage
- 150~265VAC
- Output voltage
- 12VDC
- Rated Power
- 60W
- Ripple & Noise (max.)
- 70mV(max)
- Voltage Adj. Range
- NA
- Device
- Primary-Side Regulation CV/CC Switcher for Adapters and Chargers
- Device(frequency)
- 85KHz
- VDS Voltage
- 600V(max)
- Line Regulations
- 1%
- Load Regulations
- 5%
- SCP
- Output short-circuit protection
- ARP
- Auto-restart protection reduces power delivered by >90% for output short-circuit and control loop faults (open and shorted components)
- ON/OFF control
- ON/OFF control provides constant efficiency down to very light loads – ideal for CEC regulations
- line UV
- Line brown-in/out protection
- OV
- Line overvoltage shutdown extends line surge withstand
- OTP
- Accurate thermal shutdown, hysteretic or latching
- Efficiency(Typ.)
- 80%
- Frequency Range
- 47~63HZ
- Storage Temperature
- 0-50°C
