- Input Voltage
- 180~264V AC
- Output Voltage
- 12V DC
- Current Range
- 0~8A
- Rated Power
- 96W
- Ripple & Noise (max.)
- 120mVp-p
- Voltage Adj. Range
- 11.4~12.6V
- Line Regulation
- ±1.0%
- Voltage Tolerance
- n/a
- Setup Rise Time
- 2500ms, 15ms at full load
- Hold Up Time (Typ.)
- 35ms at full load
- Load Regulation
- 5.0%
- Temperature Coefficient
- 0.03%/°C (0~50°C)
- Frequency Range
- 47~63Hz
- Efficiency (Typ.)
- 86%
- AC Current (Typ.)
- 2A/220VAC
- Inrush Current (Typ.)
- Cold Start: 50A/220V AC
- Over Load
- 110~200% rated output power, Protection type: Shut down O/P, recovers automatically
- Isolation Resistance
- I/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500V DC / 25°C / 70% RH
- Working Humidity
- 20 ~ 90% RH Non-condensing
- Vibration
- 10 ~ 500Hz, 3G 10min./1 cycle, 60min. each along X, Y, Z
- Dimension
- 186(L) x 130.5(W) x 39mm(H)
- Store Temperature
- -20 ~ +85°C
- Working Temperature
- -20 ~ +45°C
- Withstand Voltage
- I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC
