- Feature
- Description
- Lock Type
- Fail Safe (Locked when energized)
- Face Plate Dimensions
- 205L x 35W x 41H (mm)
- Bolt Type
- 16mm DIA stainless steel with 16mm throw, solid bolt with 800Kg holding force
- Voltage & Current
- DC12V, Start: 900mA, Standby: 150mA
- Autolock Time Delay
- 0, 3, 6, 9 seconds
- Signal Output
- Door status output, NC/COM
- Compatibility
- Suitable for Fully Frameless Glass Doors
- Durability & Cycle Rating
- Tested to 500,000 cycles
- Temperature & Humidity
- -20ºC ~ 60ºC, 0~90% (non-condensing)
- Material & Finish
- High Aluminum Finished faceplate, polished housing
