- Collinear Load Test
- 600/1200 pounds
- Reverse Current Protection
- MOV (Metal Oxide Varistor)
- LED Indicator
- Indicates the Power Status
- Material
- High Strength Material with Anodized Aluminum Housing
- Anti-Residual Magnetism
- Yes, Anti-Residual Magnesium Design
- Holding Force
- 280 KG (600 lbs)
- Dimension
- 250 x 48 x 27 mm
- Armature Plate
- 180 L x 38 W x 11 H (mm)
- Voltage
- 12V/24V/48V DC ±10%
- Current
- 0.48A/0.24A
- Operating Temperature
- -20°C to 60°C
- Working Mode
- Power Off to Open (Normally Closed, NC)
- Finish - Shell
- Anodized Aluminum
- Finish - Magnetic
- Zinc
- Finish - Armature
- Zinc
