- Cylinder Quantity
- Single cylinder
- Finish
- Nickel Plating
- Body Material
- Stainless Steel
- Thickness of Lock Body
- 2.0 mm
- Keys
- 5 pcs brass standard keys
- Extension Length
- 20 mm of deadbolt
- Door Thickness
- 35 mm ~ 50 mm
- Working Voltage
- 9 ~ 18 VDC
- Working Current
- 350 mA
- Static Current
- 15 mA
- Locking Method
- By collision
- Lock-Opening Delay Time
- Automatically lock within 9s if not opened
- Operating Time
- 0.5 s
- Service Life
- 500,000 times
- Regulated & Filtered
- 500 VDC Voltage
- Locking Method (Magnetic)
- Magnetic induction
- Surface Temp
- Low temperature
- Advantage
- Low noise, low consumption, long life
- Holding Force
- 1000 kg
- Open Ways from Outside
- Keys
- Open Ways from Inside
- Rotary knob
- Suitable Humidity
- 0-90% (non-condensing)
- Operating Temperature
- -40°C ~ 50°C
