- Form 'A' Alarm Contact and Tamper Switch
- Yes
- Digital Signal Analysis
- Ensures precise detection and reduces false alarms
- Slim Profile Design
- Compact design, ideal for residential use
- ABS Plastic Construction
- Offers shock and impact protection
- White Light Immunity
- Exceptional resistance to interference from white light sources
- Pet Immunity
- Up to 25 kg (55 lbs), ideal for households with pets
- Quad Linear Imaging Technology
- Enables clear analysis of body dimensions, separating humans from pets and background objects
- Advanced ASIC-based Electronics
- For high reliability and performance
- Installation
- Height calibration free and adjustable PIR sensitivity
- Package Availability
- Available in packages of 6 (LC-100-PI-6PK)
- Dimensions
- 92 mm x 62.5 mm x 40 mm (3.62" x 2.46" x 1.57")
- Weight
- 58 g (2.04 oz)
- Detection Method
- Quad (Four Element) PIR
- Power Input
- 8.2 to 16 VDC
- Current Draw (Standby)
- 8 mA (5%)
- Current Draw (Active)
- 10 mA (5%)
- Tamper Switch Contact Rating
- 0.1 Amp @ 28 VDC
- RFI Protection
- 30 V/m, 10-1000 MHz
- EMI Protection
- 50,000 V
