- Detection Method
- Acoustic Sensor
- Detection Range
- 8m
- Detection Angle
- 120°
- Sensitivity
- 2m; 4m; 6m; 8m
- Glass Type
- Float; Plate; Tampered; Wired; Laminated Leaded; Double Glazing
- Glass Thickness
- 2.4mm to 6.4mm
- Glass Size
- 0.3m x 0.3m to 3m x 3m
- Digital Processing
- Support
- Tamper Protection
- Front; Rear
- Environment Temperature Indicator
- Support
- Signal Strength Indicator
- Support
- Alarm Input
- Normally Closed; Normally Open; Impulse Count
- Power Switch
- Power Up Enrolling
- LED Indicator
- Blue (Alarm)
- Transmission Technology
- Tri-X Wireless
- Transmission Method
- Two-Way RF Wireless
- Transmission Frequency
- 433 MHz
- Transmission Security
- AES-128 Encryption
- Transmission Range (Free Space)
- 1 Km
- Frequency Hopping
- Support
- Enrolling Method
- Power Up; Remote ID; QR Code
- Power Supply
- Battery Powered
- Battery Type
- CR123A × 2
- Typical Voltage
- 3V
- Standard Battery Life
- Up to 5 years (standby time)
- Operation Temperature
- -10 °C to 55 °C (14 °F to 131 °F)
- Storage Temperature
- -20 °C to 60 °C (-4 °F to 140 °F)
- Operation Humidity
- 10% to 90%
- Dimension (WxHxD)
- 38.8mm × 107.0mm × 24.5mm
- Weight
- 83g
- Mounting Method
- Wall; Ceiling
- Application Scenario
- Indoor
- RF Frequency
- 433 MHz
- RF Modulation
- 2GFSK
- RF Range
- 900m (open area)
- Shell Material
- PC+ABS
- Dimension (WxHxD)
- 88× 88 × 32 mm (3.46" × 3.46" × 1.26")
- Weight
- 169.5 g (6.0 oz)
- Color
- Blue/Red LED flash
