- Feature
- Specification
- IP Video Input
- 1-ch (up to 5-ch)
- IP Camera Resolution Support
- Up to 2MP
- IP Compression Support
- H.265+ / H.265 / H.264+ / H.264
- Analog Video Input
- 4-ch
- BNC Interface
- 1.0 Vp-p, 75 Ω, supporting coaxitron connection
- HDTVI Input
- 1080p25, 1080p30, 720p25, 720p30
- AHD Input
- 1080p25, 1080p30, 720p25, 720p30
- HDCVI Input
- 1080p25, 1080p30, 720p25, 720p30
- CVBS Input
- Supported
- HDMI Output
- 1-ch: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
