- Storage Capacity
- 1500 Face, 1500 Card Proximity, 1500 Password, 150,000 Attendance Log, 3000 Management Log
- Full Access Control
- Wiegand In/Out, Time Zone, Exit Switch, Access Control, Door Sensor, NTP Server, Bell, Time Period, Antipass Back
- CPU
- SSD222D
- System
- RAM: Built-in 128MB DDR3, Flash: 128MB SPI NAND
- Verification Mode
- 1:1 & 1:N
- Identify Speed
- Face detection:
- Face Recognition Angle
- Left and Right: ≤30°, High and Low: ≤30°
- Basic Technology
- Deep learning, lightweight algorithm version without NNHE neural network hardware engine
- Simultaneously Identifiable Faces
- Up to 3 faces
- Camera
- Color camera: 1 million (1280*720) pixels, Infrared camera: 1 million (1280*720) pixels
- Field Angle
- 57.2° (D)
- Distance of Recognition
- Up to 3 meters
- Fill Light
- White filling light arrangement (9 SMD LEDs), Miniature infrared lamp (2 lamps with 600 Lens)
- Communication
- 10/100 Mbps Ethernet Port, 2.4 GHz Wi-Fi, P2P Cloud, USB device (Firmware burning, test channel)
- Audio Visual
- Display: 3.5″ (480*320), Voice output: Support, Touch screen: Support, Language: English
- Environment
- Working Voltage: DC 12V 2.0A, Working Temperature: -10°C ~ +60°C, Working Humidity: 20% ~ 80% RH
- Wiegand I/O
- Yes, Proximity Readers, Compatible with Multi-Door Controllers via Wiegand
- Card Reader
- Proximity
- Card Type
- Compatible with Multi-Door Controllers via Wiegand
- Controller
- Compatible with Multi-Door Controllers
- Compatible Software & SDK
- ONtime Attendance, SDK, Push Technology, Centralized Attendance Management System (Public/Static IP/Cloud)
- Platform Support
- Windows, Web and Cloud Attendance, Third Party Payroll/HRMS/ERP Applications, Time & Attendance, Canteen Management, School Attendance, Product Management, Gym & Clubs
