- Product
- Standalone Keypad
- Indoor Use
- Yes
- Backlight Keys
- Yes
- Built-in Buzzer
- Yes
- Can Connect External Reader
- Yes
- Easy to Install and Program
- Yes
- Full Programming from the Keypad
- Yes
- Low Power Consumption
- 30mA
- Standalone Keypad
- Yes
- Lock Output Current Short Circuit Protection
- Yes
- Wiegand 26 Output
- For connecting to a controller
- Supported Modes
- Card, PIN, Card + PIN
- Wiegand 26 Input
- For connecting with a reader
- Adjustable Time Settings
- Door Output time, Alarm time, Door Open time
- Built-in Light Dependent Resistor (LDR)
- For anti-tamper
- Battery
- NA
- Body Material
- Plastic
- Dimension
- 92*81*20 mm
- ID Card Capacity
- 2000
- Record Capacity
- NA
- Card Type
- Proximity Card
- Identify Mode
- Card, Password
- LED Indicator
- 2 LED Status (Green, Red)
- Keypad Type
- Numeric
- Wiegand/RS485 Interface
- Wiegand Input & Output 26/34 bit
- Communication
- NA
- Operation Humidity
- 10% ~ 80%
- Operation Temperature
- 10° C ~ 60° C
- Power
- DC 12V 3A
- Wiring Connections
- External Card Reader, Electric Lock, Exit Button
