- Fingerprint Sensor Type
- Optical Sensor
- Spatial Resolution
- 500 DPI ± 2%
- Platen Area
- 14.0 mm x 17.0 mm
- Image Size
- 276 x 336 Pixels
- Image Grayscale
- 256 (8-Bit Gray Level)
- Light Source
- Red LED
- Approx. Weight
- 0.140 kg
- Approx. Dimension (L x W x H)
- 61(L) x 91(W) x 54(H) mm
- Capture Mode
- Auto capture with built-in quality check (incorporates NIST quality considerations)
- Crypto Operation
- Hardware base RSA2048 Key Generation, AES-GCM-256, SHA-256, TRNG support
- Secure Memory
- TEE support by the device, secure memory support with key wrapping feature
- Secure Boot
- Secure boot support by the device
- Operating Voltage
- 5V ± 5% (USB Powered Device)
- Standby Current
- 50 mA
- Interface
- USB 2.0
- Operating Temperature
- 0 to 50°C
- Storage Temperature
- 0 to 50°C
- Environmental, Health and Safety
- RoHS
- Safety
- EN/IEC 62368-1, IS 13252 (Part 1)
- EMI / EMC Compliance
- CE, FCC Part 15B
- Image Quality Compliance
- FBI PIV, STQC
- IP Rating
- IP54
- Device Driver
- WHQL certified
- Operating System
- Windows 10 & above OR Android 7 & above
- Biometric Data Interchange Format
- ISO 19794-2 for minutiae & ISO 19794-4 for Image Template in Encrypted PID Data Block
