- Screen size
- 4.3 inch
- Operation method
- Capacitive touch screen
- Type
- LCD
- Lens
- 2
- Resolution
- 2 MP
- Audio quality
- Noise suppression and echo cancellation
- Wired network
- Supported
- Wi-Fi
- Supported, 2.4 G, 802.11b/g/n
- Network interface
- 1 RJ-45, 10/100 M self-adaptive
- Lock control
- 1
- Exit button
- 1
- Door contact input
- 1
- TAMPER
- 1
- RS-485
- 1 RS-485 (Half duplex, HIKVISION)
- Wiegand
- 1 Wiegand (Hik 26bit, Hik 34bit)
- USB
- 1
- Card type
- EM card
- Card reading frequency
- 125 KHz
- Power supply
- 12 VDC, 1 A (power adapter included)
- Working temperature
- -10 °C to 40 °C (14 °F to 104 °F)
- Working humidity
- 0 to 90% (No condensing)
- Dimensions
- 118.4 mm × 118.4 mm × 21.8 mm (4.66" × 4.66" × 0.86")
- Installation
- Wall mounting, base mounting
- Weight
- Gross weight: 0.71 kg (1.57 lb), Net weight: 0.23 kg (0.51 lb)
- Language
- English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean, Japanese
- Platform
- Hik-ProConnect and HikCentral Professional
- Face anti-spoofing
- Supported
