- Capacity
- 2TB
- Standard Model Number
- ST2000VN003
- Interface
- SATA 6Gb/s
- Drive Bays Supported
- 1 – 8 Bays
- Recording Technology
- CMR
- Drive Design (Air or Helium)
- Air
- Workload Rate Limit (WRL)
- 180
- Rotational Vibration (RV) Sensor
- Yes
- Dual-Plane Balance
- Yes
- Error Recovery Control
- Yes
- Max. Sustained Transfer Rate OD (MB/s)
- 180MB/s
- Spindle Speed (RPM)
- 5400RPM
- Cache (MB)
- 256MB
- Load/Unload Cycles
- 600,000
- Nonrecoverable Read Errors Rate, Max
- 1 per 10E14
- Power-On Hours
- 8,760
- Mean Time Between Failures (MTBF, hours)
- 1,000,000 hr
- Rescue Data Recovery Services (years)
- 4
- Warranty, Limited (years)
- 3
- Startup Current, Typical (12V, A)
- 1.8 A
- Average Operating Power
- 3.1 W
- Idle Power Average (W)
- 2.8 W
- Standby Mode/Sleep Mode, Typical (W)
- 0.25 W
- Operating Temperature (ambient, min°C)
- 0°C
- Operating Temperature (drive reported, max °C)
- 65°C
- Shock, Operating/Nonoperating: 2ms (max)
- 80 Gs/300 Gs
- Acoustics, Idle (dBA)
- 20
- Acoustics, Seek (dBA)
- 21
- Height (mm/in)
- 20.20 mm/0.795 in
- Width (mm/in, max)
- 101.85 mm/4.010 in
- Depth (mm/in, max)
- 146.99 mm/5.787 in
- Weight (g/lb, typical)
- 415 g/0.915 lb
- Carton Unit Quantity
- 25
- Cartons per Pallet/Cartons per Layer
- 40/8
