- Specifications
- Details
- Input Voltage
- 150V to 240V AC, 50/60Hz
- Output Voltage
- 12V DC
- Output Current
- 10 Amp (Max.)
- Output Wattage
- 120 Watt (Max.)
- Features
- Details
- BIS Approved
- Yes
- Highly Integrated SMPS Switcher I.C Design
- Yes
- Surge Protection, Over Temperature Protection
- Yes
- Over Current, Over Voltage & Over Load Protection
- Yes
- High-efficiency, low energy Consumption
- Yes
- Cable Compensation Switch For Voltage Boosting
- Yes
- Works under low voltages and protects high voltage where linear fails
- Yes
- Attractive White color with FR grade PC Cabinet
- Yes
- Inbuilt cooling fan for better heat dissipation
- Yes
- Covered Input AC & Output DC terminals for safety purpose
- Yes
- Compact size, light weight & shock proof
- Yes
- Desktop type with wall hanging hook
- Yes
- Screw type block terminals for easy installation
- Yes
- Applications
- Details
- CCTV Camera
- Yes
- Other Electronic Equipments
- Yes
- Warranty
- Details
- Warranty Period
- 1 Year
- Exclusions
- Physical damage, scratches, water or liquid damage not covered
- Replacement Policy
- Replacement against manufacturing defects only
- Additional Information
- Details
- Item Code
- PS-40T
