- Feature
- Specification
- Interface
- • 2× 10/100 Mbps Ethernet Port • 1× USB 2.0 Port • 1× Micro USB Port
- Power Supply
- 802.3af/at PoE or Micro USB (DC 5V/Minimum 1A)
- Dimensions
- 3.9×3.9×1.0 in (100×98×25 mm)
- Omada App
- Yes
- Centralized Management
- • Up to 100 Omada access points, 20 JetStream switches, and 10 Omada routers • Up to 1,000 Clients
- Cloud Access
- Yes
- L3 Management
- Yes
- Multi-site
- Yes
- Management
- • Automatic Device Discovery • Batch Configuration • Batch Firmware Upgrading • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal Configuration
- Certification
- CE, FCC, RoHS
- Package Contents
- • Omada Hardware Controller OC200 • Quick Installation Guide • Ethernet Cable
- System Requirements
- Microsoft® Windows® 10, 8, 7, Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux
- Environment
- • Operating Temperature: 0–40 ℃ (32–104 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
