- Model
- GCC6010
- Network Ports
- 2 x 2.5 Gigabit SFP ports, 5 x Gigabit Ethernet ports (All ports WAN/LAN configurable, max 3x WAN)
- Auxiliary Ports
- 1x Micro-SD, 1x USB 3.0, 1x Reset
- Memory
- 2GB RAM, 32GB eMMC Flash
- External Storage
- N/A
- Router Speed
- 2.5Gbps
- IPsec VPN Throughput
- 1Gbps
- NAT Sessions
- 160K
- IDS/IPS
- 900Mbps
- PBX Capacity
- 12 users and 4 concurrent calls (Upgradable)
- PoE Output
- 4 x PoE out ports, IEEE802.3af/at, Maximum PoE Wattage: 36W
- Mounting
- Desktop and Wall-mountable
- Material
- Metal
- LED Indicators
- 7x single LEDs, 4x PoE LEDs, 1x RGB LED for device tracking/status
- Connection Type
- DHCP, Static IP, PPPoE
- Network Protocols
- IPv4, IPv6, IEEE802.1q, IEEE 802.1p, IEEE802.1x, IEEE802.3, IEEE 802.3u, IEEE 802.3x, IEEE802.3ab
- Quality of Service (QoS)
- - VLAN, TOS - Support multiple traffic classes, filter by port, IP address, DSCP, and policing - Application QoS: App monitoring & traffic statistics - VoIP Prioritization
- Firewall
- - DDNS, Port Forwarding, DMZ, UPnP, DoS & Spoofing defense, traffic rules, NAT - DPI, Anti-Virus, IPS/IDS, SSL Proxy - Content Control: DNS filtering, web URL/class/keywords filtering, application identification and control
- VPN Support
- - IPsec VPN Client-to-Site / Site-to-Site - IPSec Encryption: 3DES, AES - IPSec Authentication: MD5, SHA-1, SHA2-256 - PPTP VPN Server / Client (MPPE 40-bit, 128-bit) - OpenVPN® Server / Client - WireGuard® Support
- Network Management
- Grandstream Device Management System (GDMS), Local Web GUI, SSH, and SNMP (v1/v2c/v3)
- Max AP/Clients
- Up to 150 GWN APs, Up to 500 Clients
- Power and Green Energy Efficiency
- Universal power adapter (Input: 100-240VAC 50-60Hz, Output: 48VDC 1A, 48W); 4 x PoE out ports, Maximum PoE Wattage: 36W
- Environmental
- Operation: 0°C to 45°C, Storage: -30°C to 60°C, Humidity: 5% to 95% Non-condensing
- Physical Dimensions & Weight
- - Unit Dimensions: 191 x 101 x 29 mm - Unit Weight: 520g - Package Dimensions: 300 x 130 x 53 mm - Package Weight: 835g
- Package Contents
- GCC6010, Universal Power Supply, Quick Installation Guide
- Compliance
- FCC, CE, RCM, IC
