- PoE Port
- 16 10/100 ports support IEEE802.3af/at
- Uplink Port
- 2GE
- SFP Port
- 1 (10G)
- PoE Port Output Power
- 15.4W/30W IEEE802.3af/at
- PoE Power Supply Pins
- Both ½+, 3/6- and 4/5+, 7/8-
- Transmission Distance
- 100 ~ 150m
- Protocol Standard
- IEEE 802.3af/IEEE 802.3at
- PoE Type
- End-span
- Network Standard
- IEEE 802.3, IEEE802.3u, 802.3x, 802.3af/at
- Network Medium
- 10/100 Mbps 5 class and above non-shielded twisted pair
- Switch Capability
- 7.2Gbps
- Forwarding Mode
- Store and forward
- Forwarding Rate
- 100Mbps: 14880pps / 1000Mbps: 14800pps
- MAC Address
- MAC address table 8K
- Port Function
- Power priority mechanism, fast and forward, MAC automatic learning and aging IEEE802.3X Full-duplex and mode and back pressure for Half-duplex mode
- Indicator
- Each port occupied 1 LINK/ACT.100Mbps, POE Status Indicator, Whole power indicator
- Working Temperature
- -10° ~ 55° C
- Input Power
- AC100-240V 50/60HZ
- Whole Power
- 250W
- Weight
- 4.125kg
- Size
- 270mm x 180mm x 44mm (L×W×H)
