- Power Adapter Voltage
- AC 110V-240V
- Consumption
- 120W
- Power Position
- Built-in Housing
- PoE Ethernet Port
- 1～8 Port: 10/100Mbps
- Ethernet Port
- Uplink Port: 10/100Mbps
- Transmission Distance
- 1～8 Port: 100Mbps: 0~100m, 10Mbps: 0~250m, Uplink Port: 0 ~ 100m
- Transmission Medium
- Cat5/5e/6 standard network cable
- Network Standard
- IEEE802.3/802.3u, IEEE802.3x, IEEE802.3ab
- Switching Capacity
- 2.0Gbps
- Packet Buffer Memory
- 1Mbits
- Throughput
- 0.9Mbps
- MAC Table
- 1K
- Packet Forwarding Rate
- 10Mbps: 14880pps/port, 100Mbps: 148800pps/port
- PoE Standard
- IEEE 802.3af/at
- PoE Power Supply
- End-Span (1/2+; 3/6-)
- PoE Power
- af=15.4W, at=30W for each port
- Port Function
- Power priority mechanism, fast and forward, MAC automatic learning and aging, IEEE802.3X Full-duplex and backpressure for Half-duplex mode
- LED Indicator
- LINK/ACT (100Mbps); PoE Status Indicator; Power indicator; Extender
- Working/Storage Temperature
- 0℃~55℃ / -20℃~70℃
- Relative Humidity
- 20~95%
