- Network Interface
- 4× PoE RJ45 (10/100 Mbps), 2× non-PoE RJ45 (10/100 Mbps)
- Protocols & Standards
- IEEE 802.3i/u/ab, 802.3af/at, 802.3x, ANSI/IEEE 802.3 NWay
- Performance
- 1.2 Gbps bandwidth, 148,800 pps at 100M
- PoE Power Output
- Total Power: 65W, Pins: 1/2(+), 3/6(-)
- LED Indicators
- Power, LINK/ACT, POE
- Protection
- 6KV Lightning Protection
- Dimensions
- 137 x 122 x 33 mm, Weight: 0.40 kg
- Environment
- 0–40°C Operating Temp, 10–90% Humidity
