- Model
- GWN7832
- Network Protocols
- IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x
- Gigabit Ethernet Ports
- 0
- Gigabit SFP Ports
- 0
- Gigabit SFP+ Ports
- 12
- Maximum Supported Modules
- SM-10G: 12, MM-10G: 12, RJ45-10G: 6
- Console
- 1
- Integrated Power Supply
- 60W
- External Redundant Power Supply
- 12V/60W
- Surge Protection
- ±6KV CM and DM for power
- ESD Protection
- ±12KV for contact discharge
- Forwarding Mode
- Store-and-forward
- Total Non-Blocking Throughput
- 120Gbps
- Switching Capability
- 240Gbps
- Forwarding Rate
- 178.56Mpps
- Packet Buffer
- 16Mb
- MAC Addresses
- 32K MAC addresses
- VLANs
- 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN
- Link Aggregation
- 6 link aggregation
- Spanning Tree
- 64 instances for STP/RSTP/MSTP
- Routing
- Static routing, Dynamic routing (RIP, RIPng, OSPF, OSPFv3), Policy routing (pending)
- Multicast
- IGMP Snooping with IGMPv2 and IGMPv3, MLD Snooping with MLDv1 and MLDv2
- QoS/ACL
- 4K ACL for Ethernet, IPv4, IPv6, Port priority, Traffic shaping, Rate limit
- DHCP
- DHCP server, DHCP relay, Option 82, 60, 160, 43
- Security
- User management, HTTPS, SSH, Telnet, 802.1X authentication, AAA (RADIUS, TACACS+), DoS prevention, DHCP Snooping
- Mounting
- Desktop, Wall-Mount, Rack-Mount (kits included)
- LED Indicators
- 12x bi-color LEDs for 1G/10G
- Fan
- 2
- Environmental
- Operation: 0°C to 45°C, Storage: -10°C to 60°C, Humidity: 10% to 90% RH (Non-condensing)
- Dimensions
- 440mm (L) x 200mm (W) x 44mm (H)
- Unit Weight
- 2.67Kg
- Package Contents
- 1x Switch, 1x 1.2m (10A) AC Cable, 1x 25cm Ground Cable, 4x Rubber Footpads, 1x Power Cord Anti-Trip, 2x Rack-Mounting Kits, 8x Screws (KM 3*6), 1x Quick Installation Guide, 1x Console Cable (Optional)
- Compliance
- FCC, CE, RCM, IC, UKCA
