- Attribute
- Specification
- Lead time
- Usually in Stock
- Run time for load
- 360 W (Min-max: 36-360 W)
- Max. Capacity Used
- 100 %
- Main Input Voltage
- 230 V
- Main Output Voltage
- 230 V
- Rated power in W
- 360 W
- Rated power in VA
- 600 VA
- Product or component type
- Uninterruptible power supply (UPS)
- Output connection type
- 3 India 3-pin 6A
- Cable length
- 1.2 m
- Number of cables
- 1
- Battery type
- Lead-acid battery
- Run Time
- View Runtime Graph
- Number of battery filled slots
- 0
- Number of battery free slots
- 0
- Battery recharge time
- 6 h
- Number of battery replacement quantity
- 1
- Battery voltage
- 12 V
- Battery graph comments
- Curve fit to measured runtime data. All measurements taken with new, fully charged batteries, at typical environmental conditions, with no electrical input and balanced resistive load (PF = 1.0) output.
- Extended runtime
- 0
- Replacement battery
- RBC2
- Provided equipment
- User manual
- Number of power module free slots
- 0
- Number of power module filled slots
- 0
- Redundant
- No
- Color
- Black
- Height
- 21.8 cm
- Width
- 10.7 cm
- Depth
- 23.7 cm
- Net weight
- 4.7 kg
- Mounting preference
- No preference
- Mounting mode
- Not rack-mountable
- Two post mountable
- 0
- USB compatible
- No
- Network frequency
- 45...65 Hz auto-sensing
- Plug standard
- India 3-pin 6A
- Input voltage limits
- 145...290 V
- Maximum configurable power in W
- 360 W
- Output frequency
- 50 Hz sync to mains
- UPS type
- Line interactive
- Wave type
- Stepped approximation to a sinewave
- Full load runtime
- 360 W
- Maximum configurable power in VA
- 600 VA
- Transfer time
- 10 ms typical : 12 ms maximum
- Product certifications
- BIS
- Ambient air temperature for operation
- 0…40 °C
- Relative humidity
- 0…95 %
- Operating altitude
- 0...3000 m
- Ambient air temperature for storage
- -15…45 °C
- Storage Relative Humidity
- 0…95 %
- Storage altitude
- 0…15000 m
- Acoustic level
- 45 dBA
- Control panel
- LED status display with on line: on battery: replace battery and building wiring fault
- Alarm
- Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm
- Surge energy rate
- 255 J
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 29.5 cm
- Package 1 Width
- 31 cm
- Package 1 Length
- 16.5 cm
- Package 1 Weight
- 5.2 kg
- Warranty
- 2 years repair or replace
