- Category
- Specification
- Model No.
- R-PL750D-FC0B-IN-V2
- Cables
- Main Power Connector (20+4)Pin x 1 – 1PCS CPU(4+4)Pin x 1– 2PCS PCI-E(6+2)Pin x 1 – 1PCS PCI-E(6+2)Pin x 2 – 1PCS 12V-2x6(16Pin) x 1 – 1PCS SATA x 4 + 4Pin Peripheral x 1 – 2PCS
- Type
- ATX12V V3.0
- Product Dimensions
- 150×140×86mm (W x L x H)
- Efficiency Certification
- 80Plus Bronze
- Fan Size
- 120mm
- Fan Bearing
- HYB (Hydro Bearing)
- Topology
- Active PFC+DC to DC
- Capacitors
- Chinese Electrolytic Capacitors
- Power Good Signal
- 100-150ms
- Hold Up Time
- ≥16ms
- Efficiency
- ≥85% Under Typical Load (50% Loading)
- Protection
- OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
- Operation Temperature
- 0 - 40℃
- Regulatory
- CE/FCC/CCC/RCM/EAC/CAN ICES-003(B)/NMB-003(B)/TUV-RH
- Erp Regulation
- ErP 2014
- Environment Protection
- WEEE/中国 RoHS/Triman/P65
- MTBF
- 100,000 Hours
- Warranty
- 5 Years
