- Main Point
- Specification
- CPU
- Supports Intel® Core™ Ultra Processors (Series 2), LGA 1851
- Chipset
- Intel B860
- Memory
- 4x DDR5 UDIMM, up to 256GB Up to 8800+ MT/s (OC), Intel® XMP 3.0, Dual Controller Dual-Channel, Non-ECC, CUDIMM
- Graphics
- 1x HDMI 2.1 (4K@60Hz) 1x DisplayPort 1.4 (4K@60Hz) 1x Thunderbolt™ 4 Type-C (DP 2.1 up to 8K@60Hz)* *Available only with processors featuring integrated graphics
- PCIe Slots
- 4x PCIe x16 PCI_E1: PCIe 5.0 x16 (From CPU) PCI_E2-E4: PCIe 4.0 (x1/x4 from Chipset)
- Storage
- 3x M.2 (1x PCIe 5.0 from CPU, 2x PCIe 4.0 from Chipset) 4x SATA 6Gb/s RAID 0/1/5/10 (SATA only)
- LAN & Wireless
- Realtek® 8126 5Gbps LAN Intel® Wi-Fi 7 + Bluetooth® 5.4 (Pre-installed)
