- Main Point
- Specification
- CPU
- Supports AMD Ryzen™ 9000/8000/7000 Series Desktop Processors, Socket AM5
- Chipset
- AMD X870E
- Memory
- 4x DDR5 UDIMM, up to 256GB Up to 8400+ MT/s (OC), AMD EXPO™, Dual Channel, Non-ECC, CUDIMM
- Graphics
- 1x HDMI 2.1 (8K@60Hz)* 2x USB4® Type-C (DisplayPort 1.4, 4K@60Hz)* *Available only with processors featuring integrated graphics
- PCIe Slots
- 3x PCIe x16 PCI_E1: PCIe 5.0 x16 / 4.0 x8 / x4 (CPU dependent) PCI_E2: PCIe 3.0 x1 PCI_E3: PCIe 4.0 x4
- Storage
- 4x M.2 (2x PCIe 5.0 from CPU, 2x PCIe 4.0 from Chipset) 4x SATA 6Gb/s RAID 0/1/5/10 for NVMe (RAID 5 with Ryzen 9000 only)
- LAN & Wireless
- Realtek® 8126 5G LAN Wi-Fi 7
