- Main Point
- Specification
- CPU
- Supports AMD Ryzen™ 9000/8000/7000 Series Desktop Processors, Socket AM5
- Chipset
- AMD B850
- Memory
- 4x DDR5 UDIMM, up to 256GB Supports up to 8400+ MT/s (OC), AMD EXPO™, Dual Channel, Non-ECC, CUDIMM
- Graphics
- 1x HDMI 2.1 (8K@60Hz)* *Available only on processors with integrated graphics
- PCIe Slots
- 3x PCIe x16 PCI_E1: PCIe 5.0 x16 / 4.0 x8 / x4 (CPU dependent) PCI_E2: PCIe 3.0 x1 PCI_E3: PCIe 4.0 x4 (x2 if M.2_3 in use)
- Storage
- 4x M.2 (2x PCIe 5.0 x4 from CPU, 2x PCIe 4.0 from Chipset) 4x SATA 6Gb/s RAID 0/1/10 for NVMe (9000/7000 CPUs only)
- LAN & Wireless
- Realtek® 8126 5G LAN Wi-Fi 7
