- Brand
- MSI
- Model
- B860M GAMING PLUS WIFI6E
- Chipset
- Intel B860
- Processor Support
- Intel® Core™ Ultra Processors (Series 2), LGA1851 Socket
- Memory
- 4 × DDR5 UDIMM, Up to 256GB, Supports DDR5 8800+ MT/s (OC), Intel XMP 3.0 & CUDIMM
- Expansion Slots
- 1 × PCIe 5.0 x16, 1 × PCIe 4.0 x4, 2 × PCIe 4.0 x1
- Storage
- 3 × M.2 (1 × PCIe 5.0, 2 × PCIe 4.0), 4 × SATA 6Gb/s
- Graphics Output
- 1 × HDMI 2.1, 1 × DisplayPort 1.4 (Up to 4K @ 60Hz)
- Networking
- Intel® Killer™ 5GbE LAN, Wi-Fi 6E, Bluetooth 5.3
- Audio
- Realtek® ALC897 7.1-Channel HD Audio
- USB Ports
- USB 10Gbps Type-A & Type-C, USB 5Gbps Type-A & Type-C, USB 2.0
- Special Features
- Thunderbolt 5 Header, TPM 2.0, EZ Debug LED, RGB Headers
