- Feature
- Description
- Function
- Expands 1-port RS-232 COM and 1-port IEEE1284 LPT on system
- Serial Speed
- RS-232 Serial port data communication speeds up to 921.6Kbps
- Controller
- High reliable SUNIX SUN2410 native PCI Express UART and IEEE1284 controller
- PCIe Specification
- Designed to meet PCI Express Base Specification Revision 2.0
- PCIe Lanes
- Supports x1, x2, x4, x8, x16 (lane) PCI Express Bus connector keys
- Flow Control
- On-chip hardware auto flow control to guarantee no data loss
- ESD Protection
- Built-in ±15KV ESD protection for all serial signals (IEC1000-4-2)
- Parallel Port Standard
- Supports IEEE 1284-1994 parallel port standard
- Parallel Modes
- ECP / EPP / SPP / BPP
- Installation
- Plug-n-Play, I/O address and IRQ assigned by system
- Certifications
- CE, FCC, RoHS, Microsoft WHQL
- OS Support
- Microsoft Windows, Linux, and DOS
