- Attribute
- Specification
- Model
- TS-832PX-4G
- CPU
- AnnapurnaLabs Alpine AL324 ARM® Cortex-A57 4-core 1.7GHz processor
- CPU Architecture
- 64-bit ARM
- Floating Point Unit
- Yes
- Encryption Engine
- Yes
- System Memory
- 4 GB SODIMM DDR4 (1 x 4 GB)
- Maximum Memory
- 16 GB (1 x 16 GB)
- Memory Slot
- 1 x SODIMM DDR4
- Flash Memory
- 512 MB (Dual boot OS protection)
- Drive Bay
- 8 x 3.5-inch SATA 6Gb/s
- Drive Compatibility
- 3.5-inch SATA HDDs, 2.5-inch SATA HDDs, 2.5-inch SATA SSDs
- Hot-swappable
- Yes
- M.2 Slot
- Optional via PCIe adapter
- SSD Cache Acceleration Support
- Yes
- 2.5 Gigabit Ethernet Port
- 2 (2.5G/1G/100M/10M)
- 10 Gigabit Ethernet Port
- 2 x 10GbE SFP+
- Wake on LAN (WOL)
- Only the 2.5GbE port
- Jumbo Frame
- Yes
- PCIe Slot
- 1 (PCIe Gen 2 x2)
- USB 3.2 Gen 1 Port
- 3
- Form Factor
- Tower
- LED Indicators
- System Status, LAN, USB, HDD1-8
- Buttons
- Power, Reset, USB Copy
- Dimensions (HxWxD)
- 180.2 × 329.3 × 280.8 mm (excluding foot pad)
- Weight (Net)
- 7.05 kg
- Weight (Gross)
- 8 kg
- Operating Temperature
- 0 - 40 °C (32°F - 104°F)
- Storage Temperature
- -20 - 70 °C (-4°F - 158°F)
- Relative Humidity
- 5-95% RH non-condensing (wet bulb: 27˚C/80.6˚F)
- Power Supply Unit
- 250W, 100-240V AC, 50/60Hz, 3.5A
- Power Consumption: HDD Sleep Mode
- 27.949 W
- Power Consumption: Operating Mode, Typical
- 50.858 W (tested with drives fully populated)
- Fan
- System fan: 2 x 120mm, 12VDC, CPU fan: 1 x 60mm
- System Warning
- Voice prompts or Buzzer
- Kensington Security Slot
- Yes
- Standard Warranty
- 2 Years
- Max. Number of Concurrent Connections (CIFS) - with Max. Memory
- 700
