- Attribute
- Specification
- Model
- TS-873A-8G
- CPU
- AMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor
- CPU Architecture
- 64-bit x86
- Graphic Processors
- Optional via a PCIe adapter
- Floating Point Unit
- Yes
- Encryption Engine
- AES-NI
- Hardware-accelerated Transcoding
- Optional via a PCIe adapter
- System Memory
- 8 GB SODIMM DDR4 (1 x 8 GB)
- Maximum Memory
- 64 GB (2 x 32 GB)
- Memory Slot
- 2 x SODIMM DDR4
- Support ECC memory
- Yes
- Flash Memory
- 5GB (Dual boot OS protection)
- Drive Bay
- 8 x 3.5-inch SATA 6Gb/s, 3Gb/s
- Drive Compatibility
- 3.5-inch SATA hard disk drives, 2.5-inch SATA solid state drives
- Hot-swappable
- Yes
- M.2 Slot
- 2 x M.2 2280 PCIe Gen3 x1 slots
- SSD Cache Acceleration Support
- Yes
- GPU pass-through
- Yes
- 2.5 Gigabit Ethernet Port
- 2 (2.5G/1G/100M)
- 5 Gigabit Ethernet Port
- Optional via a PCIe adapter
- 10 Gigabit Ethernet Port
- Optional via a PCIe adapter
- Wake on LAN (WOL)
- Yes
- Jumbo Frame
- Yes
- PCIe Slot
- 2 (PCIe Gen 3 x4)
- USB 3.2 Gen 2 (10Gbps) Port
- 3 x Type-A USB 3.2 Gen 2 10Gbps, 1 x Type-C USB 3.2 Gen 1 5Gbps
- HDMI™ Output
- Optional via a PCIe adapter
- Form Factor
- Tower
- LED Indicators
- Status/Power, USB, LAN, Drive 1-8, M.2 SSD 1-2
- Buttons
- Power, Reset, USB Auto Copy
- Dimensions (HxWxD)
- 180.2 × 329.3 × 279.6 mm
- Weight (Net)
- 7.4 kg
- Weight (Gross)
- 8.3 kg
- Operating Temperature
- 0 - 40 °C (32°F - 104°F)
- Storage Temperature
- -20 - 70°C (-4°F - 158°F)
- Relative Humidity
- 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
- Power Supply Unit
- 250W, 100-240V AC, 50-60Hz, 3.5A
- Power Consumption: HDD Sleep Mode
- 25.668 W
- Power Consumption: Operating Mode, Typical
- 54.067 W (tested with drives fully populated)
- Fan
- System fan: 2 x 120mm, CPU fan: 1 x 60mm
- System Warning
- Buzzer
- Kensington Security Slot
- Yes
- Standard Warranty
- 3 Years
- Max. Number of Concurrent Connections (CIFS) - with Max. Memory
- 2000
