- Parameter
- Specification
- Inner Conductor DC Resistance
- Max. 3.55 Ω/Km @ 20°C
- Capacitance (Nominal)
- 53.0 pF/m
- Characteristic Impedance
- 75 ± 3 Ohm
- Structural Return Loss (Min.)
- 15 dB @ 1–1000 MHz
- Nominal Velocity Ratio
- 85%
- Inner Conductor
- Solid Bare Copper (Co-axial Video Cable)
- Dielectric
- Gas Injected Physical Foam Polyethylene
- Shielding
- 1st Shield: Bonded Aluminum Tape 2nd Shield: Aluminum Alloy Braid
- Power Cores
- 3 Power Cores – Solid Copper Conductor
- Outer Jacket
- Flame Retardant PVC Jacket, ST1 Grade (IS 5831), Black
