- Spatial Resolution
- 50% 1.0 LP/mm
- Pixel Resolution
- > 10 pixels/mm
- Image Margins (Left & Right)
- >= 0.6x iris radius
- Image Margins (Top & Bottom)
- >= 0.2x iris radius
- Imaging Wavelength
- 700-900 nm
- Pixel Depth
- 8 bits/pixel
- Output Image
- KIND1 to KIND7 with JPEG2000 compression
- Capture Mode
- Auto capture with built-in quality check
- Safety Exempt Group
- Per IEC 62471:2006-07
- ESD Air Discharge
- 8 KV, contact type ±4 KV
- Radiated Emission
- FCC part 15B / IEC: CISPR 22 CLASS B standard
- Radiated Immunity
- As per IEC/EN 61000-4-3:2006 + A2:2010
- Health Safety
- RoHS Compliant
- Connectivity
- USB 2.0 / USB 1.1
- Operating System Support
- Windows XP, Windows 7, Windows 2008, Android, Linux, Embedded Linux
